Vehicle Mount Thermal Fogger – SM700 Dual Nozzle

Engine	50.8 Hp. Total
Burn Cell Frequency	32.200 Kcal/H. Total
Tank	150 Lt. (Stainless steel)
Fuel Tank	14 Lt. Total
Formulation Consumption	10 – 110 Lt / H. (Adjustable with nozzles)
Fuel Consumption	4 Lt./H. Total
Formulation Tank Pressure	0.2 Bar
Fuel Tank Pressure	0.2 Bar
Battery	12 Volt Dc., 60 Ah.
Weight	50 Kg.
Dimensions	162cm x 51cm x 38cm ( L x W x H )

Engine

50.8 Hp. Total

Burn Cell Frequency

32.200 Kcal/H. Total

Tank

150 Lt. (Stainless steel)

Fuel Tank

14 Lt. Total

Formulation Consumption

10 – 110 Lt / H. (Adjustable with nozzles)

Fuel Consumption

4 Lt./H. Total

Formulation Tank Pressure

0.2 Bar

Fuel Tank Pressure

0.2 Bar

Battery

12 Volt Dc., 60 Ah.

Weight

50 Kg.

Dimensions

162cm x 51cm x 38cm ( L x W x H )

Working Principle;

The SM900 fumigation machines thermal fogger has a remote control and gasoline operated 57,3 Hp pulse jet engine. Thanks to the high power engine a temperature of 1200°C is developed in the combustion cell. At the end section of the nozzle this temperature falls down to 450°C, and the formulation liquid is transferred to the area, where the temperature is 450°C. During this meeting the oil-based formulation is converted into vapour state and the spraying process will be realized.

Utilization Areas;

It is used as disinfection fogger in the fight against the Covid-19 virus.
In areas of environment health and public health it is used for insecticide space treatment purposes.
It is used with pest control purposes in vector fighting against bugs i.e. mosquitos, houseflies, locust.
It is used for agricultural spraying and in greenhouses.
With anti-freeze it is used for protection against agri-frost.
